AVE 2
MANUFACTURER : BORCAD
Birthing bed AVE2 is perfectly suitable for labor, delivery, recovery and postpartum in the childbirth phases, so women in labor and their families can complete normal childbearing feeling like being in their homelike rooms
DETAILED DESCRIPTION
TECHNICAL SPECIFICATIONS
ACCESSORIES
RELATED FILES
VIDEO

Birthing bed AVE2 is perfectly suitable for labor, delivery, recovery and postpartum in the childbirth phases. So, women in labor and their families can complete normal childbearing feeling like being in their homelike rooms.

Retractable foot section

Simple swivel mechanism to hide the foot section which is fast and easy for delivery. It remains attached to bed, no storage on the floor means infection prevention and prevention of dorsal injuries from being incurred by the personnel when manipulating with the product.



Legrests concept

The firm conception of leg rests enables the care team to respond very quickly and effectively to different situations which may occur during the delivery.

Independent seat tilting

The unique oval shape creating space needed for perineal access fits closely to the birthing tub minimizing transfer gaps.

Column concept

Innovative telescopic solution provides extra low height for accessing the bed safely and extra height for treatment.

Simple controls

Integrated control panel with clear pictograms and symbols for woman in labor and nursing staff. Nurses control locking of controlling movements.

Hygiene and safety

High hygienic standard and compact construction of particular sections of the rest area and the plastic cover of the bed base reduce the time needed for the cleaning of the bed.

Colour

The bed is provided in the these colours:

Total length of the lying area: 2122 mm

Minimum length in the default setting: 1570 mm

Full width: 980 mm

Castor size: 150 mm

Minimum height: 600 mm

Maximum height: 1050 mm

Back section: -10°/+70°

Seat section: 0°/+18,5°

Trendelenburg position: 0°/-10°

Leg rests vertical: 0°/+143°

Leg rests horizontal: 0°/+60°

Foot section adjustment angle: 0°/-22°

Maximum patient load: 240 kg

Overall product weight: 245 kg



Batteries – back-up: 24V/2,3 Ah

Voltage – input: 230 V

Motor voltage: 24 V

Ingress protection of the birthing bed: IPX4

Device class: I

Classification of applied parts: B

  • Sliding stainless catch basin 4.5l
  • Telescopic infusion stand
  • Stainless steel bowl with castors
  • Removable Headboard
  • Front holder
  • Under bed light
  • Upper mattress
  • Euro lath
  • Supporting upholstered bar
  • Doctor ‘s chair
  • Remote control
  • Lumbar support designed bolster
DETAILED DESCRIPTION
TECHNICAL SPECIFICATIONS
ACCESSORIES
RELATED FILES
VIDEO

Birthing bed AVE2 is perfectly suitable for labor, delivery, recovery and postpartum in the childbirth phases. So, women in labor and their families can complete normal childbearing feeling like being in their homelike rooms.

Retractable foot section

Simple swivel mechanism to hide the foot section which is fast and easy for delivery. It remains attached to bed, no storage on the floor means infection prevention and prevention of dorsal injuries from being incurred by the personnel when manipulating with the product.



Legrests concept

The firm conception of leg rests enables the care team to respond very quickly and effectively to different situations which may occur during the delivery.

Independent seat tilting

The unique oval shape creating space needed for perineal access fits closely to the birthing tub minimizing transfer gaps.

Column concept

Innovative telescopic solution provides extra low height for accessing the bed safely and extra height for treatment.

Simple controls

Integrated control panel with clear pictograms and symbols for woman in labor and nursing staff. Nurses control locking of controlling movements.

Hygiene and safety

High hygienic standard and compact construction of particular sections of the rest area and the plastic cover of the bed base reduce the time needed for the cleaning of the bed.

Colour

The bed is provided in the these colours:

Total length of the lying area: 2122 mm

Minimum length in the default setting: 1570 mm

Full width: 980 mm

Castor size: 150 mm

Minimum height: 600 mm

Maximum height: 1050 mm

Back section: -10°/+70°

Seat section: 0°/+18,5°

Trendelenburg position: 0°/-10°

Leg rests vertical: 0°/+143°

Leg rests horizontal: 0°/+60°

Foot section adjustment angle: 0°/-22°

Maximum patient load: 240 kg

Overall product weight: 245 kg



Batteries – back-up: 24V/2,3 Ah

Voltage – input: 230 V

Motor voltage: 24 V

Ingress protection of the birthing bed: IPX4

Device class: I

Classification of applied parts: B

  • Sliding stainless catch basin 4.5l
  • Telescopic infusion stand
  • Stainless steel bowl with castors
  • Removable Headboard
  • Front holder
  • Under bed light
  • Upper mattress
  • Euro lath
  • Supporting upholstered bar
  • Doctor ‘s chair
  • Remote control
  • Lumbar support designed bolster
DETAILED DESCRIPTION

Birthing bed AVE2 is perfectly suitable for labor, delivery, recovery and postpartum in the childbirth phases. So, women in labor and their families can complete normal childbearing feeling like being in their homelike rooms.

Retractable foot section

Simple swivel mechanism to hide the foot section which is fast and easy for delivery. It remains attached to bed, no storage on the floor means infection prevention and prevention of dorsal injuries from being incurred by the personnel when manipulating with the product.



Legrests concept

The firm conception of leg rests enables the care team to respond very quickly and effectively to different situations which may occur during the delivery.

Independent seat tilting

The unique oval shape creating space needed for perineal access fits closely to the birthing tub minimizing transfer gaps.

Column concept

Innovative telescopic solution provides extra low height for accessing the bed safely and extra height for treatment.

Simple controls

Integrated control panel with clear pictograms and symbols for woman in labor and nursing staff. Nurses control locking of controlling movements.

Hygiene and safety

High hygienic standard and compact construction of particular sections of the rest area and the plastic cover of the bed base reduce the time needed for the cleaning of the bed.

Colour

The bed is provided in the these colours:

TECHNICAL SPECIFICATIONS

Total length of the lying area: 2122 mm

Minimum length in the default setting: 1570 mm

Full width: 980 mm

Castor size: 150 mm

Minimum height: 600 mm

Maximum height: 1050 mm

Back section: -10°/+70°

Seat section: 0°/+18,5°

Trendelenburg position: 0°/-10°

Leg rests vertical: 0°/+143°

Leg rests horizontal: 0°/+60°

Foot section adjustment angle: 0°/-22°

Maximum patient load: 240 kg

Overall product weight: 245 kg



Batteries – back-up: 24V/2,3 Ah

Voltage – input: 230 V

Motor voltage: 24 V

Ingress protection of the birthing bed: IPX4

Device class: I

Classification of applied parts: B

ACCESSORIES
  • Sliding stainless catch basin 4.5l
  • Telescopic infusion stand
  • Stainless steel bowl with castors
  • Removable Headboard
  • Front holder
  • Under bed light
  • Upper mattress
  • Euro lath
  • Supporting upholstered bar
  • Doctor ‘s chair
  • Remote control
  • Lumbar support designed bolster
