Defibrillator-Monitor MEDUCORE Standard

The defibrillator-monitor MEDUCORE Standard2, from the German manufacturer Weinmann Emergency Medical Technology GmbH + CO. KG, is used as a portable external defibrillator with monitoring functions in a patient who shows symptoms of cardiac arrest or arrhythmias in the heart rhythm. Besides, it can also be used to transport the patient between hospitals and other facilities by ambulance, airplane, helicopter or even ship. It is also used when the measured values of the measurement functions built into the device are to be recorded. MEDUCORE Standard2 is suitable for use in patients of all ages who require emergency treatment.


MEDUCORE Standard2 is powered by a built-in rechargeable battery, which ensures electrical autonomy of up to approximately 4 hours in continuous monitoring mode of the patient’s hemodynamic parameters or up to 350 defibrillations at 200 joules. It has small dimensions (W: 242 mm x H: 137 mm x D: 130 mm) and a weight of 2.75 Kg including the battery.

In detail, MEDUCORE Standard2 has the following monitoring and diagnostic functions:

  • 6-channel ECG
  • 12 channel ECG (optionally available)
  • Pulse oximetry (optionally available)
  • Non-invasive NiBP pressure measurement

The device also has the following treatment – defibrillation functions.

  • Semi-automatic defibrillation – AED mode
  • Manual defibrillation and cardioversion – MANUAL mode (optionally available)

The following optional functions can also be added:

  • Replay view (optionally available).
  • 12-derivative ECG transmission (optionally available).
  • Upload session data (optionally available).

The MEDUCORE Standard2 defibrillator has electric shock protection, is resistant to mechanical stress, waterproof, protected against foreign particle ingress, dust ingress IP55 and operates reliably under the following conditions:

  • Temperature ranges from -20 to +55°C
  • Humidity range 15%-95%
  • Atmospheric pressure 540 hPa to 1100 hPa
  • Altitude from sea level -500 m to 5,000 m

Complies with these standards: EN 60601-1, EN 60601-1-2, EN 60601-1-6, EN 60601-1-6, EN 60601-1-8, EN 60601-1-12, EN 60601-2-4, EN 60601-2-25, EN 60601-2-27, EN 60601-2-49, EN 80601-2-30, EN 80601-2-61, EN 1789, EUROCAE ED-14G (RTCA DO 160 G), MIL-STD 810 G
