EG-3270UK SLIM ULTRASOUND GASTROSCOPE
SPECIALTIES : Gastroenterology
The EG-3270UK combines the feasibility of Fine Needle Aspiration (FNA) with excellent ultrasound image quality in an ergonomically engineered endoscope. This unique combination sets a new standard in endoscopic ultrasound for everyday practice and a wide range of procedures.
DETAILED DESCRIPTION
TECHNICAL SPECIFICATIONS
ACCESSORIES
RELATED FILES
VIDEO

State-of-the-art images

The EG-3270UK delivers high-resolution ultrasound imaging and great visualization capabilities with its curved, linear-array transducer. When combined with its EUS-FNA function that is supported by Hitachi Real-time Tissue Elastography (HI-RTE) and Doppler capabilities, the EG-3270K’s state-of-the-art imaging provides multiple methods to assess organs, lymph nodes and masses.

Ergonomic engineering, comfortable efficiency

The flexibility and advanced maneuverability of the EG-3270UK make EUS procedures easier for physicians and more comfortable for patients. Combined with an exceptionally small distal end, these features facilitate intubation and advancement up to the duodenum for more successful procedures.

Multifunctional design

The EG-3270UK features a 2.8-mm instrument channel and a secure elevator for excellent EUS-FNA capabilities as well as day-to-day ultrasound endoscopic procedures. The EG-3270UK can meet the high demand for EUS procedures in the upper gastrointestinal tract and also facilitate staging for lung cancer patients.

  • Product: EG-3270UK
  • Insertion Tube Diameter (mm): 10.8
  • Instrument Channel Diameter* (mm): 2.8
  • Working Length (mm): 1250
  • Total Length (mm): 1560
  • Angle of View (°): 120 (50° Forward oblique)
  • Focal Range (mm): 5-100
  • Angulation:
    • Up / Right: 130-130
    • Down / Left (°): 120-120
  • Rigid Distal width:
    • Probe: 11.5
    • Optic: 12
  • Scan Direction: Longitudinal
  • Scan System: Convex
  • Scan Angle: 120
  • Acoustic Frequency (MHz switchable): 5-10
  • Ballon: Removable
